Problem Statement

Hint

Try it yourself

Solution

Solution Explanation

Runtime Complexity

Memory Complexity

Solution Breakdown

#include <iostream>
#include <vector>
using namespace std;
class vertex {
private:
  int id;
  bool visited;
public:
  vertex(int id, bool visited) {
    this->id = id;
    this->visited = visited;
  }
  int getId() {
    return id;
  }
  void setId(int id) {
    this->id = id;
  }
  bool isVisited() {
    return visited;
  }
  void setVisited(bool visited) {
    this->visited = visited;
  }
};
class edge {
private:
  int weight;
  bool visited;
  vertex* src;
  vertex* dest;
public:
  edge(int weight, bool visited, vertex* src, vertex* dest){
    this->weight = weight;
    this->visited = visited;
    this->src = src;
    this->dest = dest;
  }
  int getWeight() const {
    return weight;
  }
  void setWeight(int weight) {
    this->weight = weight;
  }

  bool isVisited() const {
    return visited;
  }
  void setVisited(bool visited) {
    this->visited = visited;
  }
  vertex* getSrc() const {
    return src;
  }
  void setSrc(vertex* src) {
    this->src = src;
  }
  vertex* getDest() const {
    return dest;
  }
  void setDest(vertex* dest) {
    this->dest = dest;
  }
};
class graph {
private:
  vector<vertex*> g;    //vertices
  vector<edge*> e;      //edges
public:
  int find_min_spanning_tree(){

    //TODO: Write - Your - Code
  }

  const vector<vertex*>& getG() const {
    return g;
  }
  void setG(const vector<vertex*>& g) {
    this->g = g;
  }
  const vector<edge*>& getE() const {
    return e;
  }
  void setE(const vector<edge*>& e) {
    this->e = e;
  }
  // This method returns the vertex with a given id if it
  // already exists in the graph, returns NULL otherwise
  vertex* vertex_exists(int id) {
    for (int i = 0; i < this->g.size(); i++) {
      if (g[i]->getId() == id) {
        return g[i];
      }
    }
    return nullptr;
  }
  string print_graph() {
    string result = "";
    for (int i = 0; i < g.size(); i++) {
      cout<<g[i]->getId()<< ' ' <<g[i]->isVisited()<< endl;
    }
    cout << endl;
    for (int i = 0; i < e.size(); i++) {
      result += "[" + std::to_string(e[i]->getSrc()->getId()) + "->" + std::to_string(e[i]->getDest()->getId()) + "],";
      cout << e[i]->getSrc()->getId() << "->"
          << e[i]->getDest()->getId() << "["
          << e[i]->getWeight() << ", "
          << e[i]->isVisited() << "]  ";
    }
    cout << endl << endl;
    return result;
  }

  // This method generates the graph with v vertices
  // and e edges
  void generate_graph(int vertices,
      vector< vector<int> > edges) {
    // create vertices
    for (int i = 0; i < vertices; i++) {
      vertex* v = new vertex(i + 1, false);
      this->g.push_back(v);
    }
    // create edges
    for (int i = 0; i < edges.size(); i++) {
      vertex* src = vertex_exists(edges[i][1]);
      vertex* dest = vertex_exists(edges[i][2]);
      edge* e = new edge(edges[i][0], false, src, dest);
      this->e.push_back(e);
    }
  }
};

#include <iostream>
#include <vector>
using namespace std;
class vertex {
  private:
  int id;
  bool visited;
  public:
  vertex(int id, bool visited) {
    this->id = id;
    this->visited = visited;
  }
  int getId() {
    return id;
  }
  void setId(int id) {
    this->id = id;
  }
  bool isVisited() {
    return visited;
  }
  void setVisited(bool visited) {
    this->visited = visited;
  }
};
class edge {
  private:
  int weight;
  bool visited;
  vertex* src;
  vertex* dest;
  public:
  edge(int weight, bool visited, vertex* src, vertex* dest){
    this->weight = weight;
    this->visited = visited;
    this->src = src;
    this->dest = dest;
  }
  int getWeight() const {
    return weight;
  }
  void setWeight(int weight) {
    this->weight = weight;
  }
  bool isVisited() const {
    return visited;
  }
  void setVisited(bool visited) {
    this->visited = visited;
  }
  vertex* getSrc() const {
    return src;
  }
  void setSrc(vertex* src) {
    this->src = src;
  }
  vertex* getDest() const {
    return dest;
  }
  void setDest(vertex* dest) {
    this->dest = dest;
  }
};
class graph {
  private:
  vector<vertex*> g;    //vertices
  vector<edge*> e;      //edges
  public:
  const vector<vertex*>& getG() const {
    return g;
  }
  void setG(const vector<vertex*>& g) {
    this->g = g;
  }
  const vector<edge*>& getE() const {
    return e;
  }
  void setE(const vector<edge*>& e) {
    this->e = e;
  }
  // This method returns the vertex with a given id if it
  // already exists in the graph, returns NULL otherwise
  vertex* vertex_exists(int id) {
    for (int i = 0; i < this->g.size(); i++) {
      if (g[i]->getId() == id) {
        return g[i];
      }
    }
    return nullptr;
  }
  // This method generates the graph with v vertices
  // and e edges
  void generate_graph(int vertices,
                      vector< vector<int> > edges) {
    // create vertices
    for (int i = 0; i < vertices; i++) {
      vertex* v = new vertex(i + 1, false);
      this->g.push_back(v);
    }
    // create edges
    for (int i = 0; i < edges.size(); i++) {
      vertex* src = vertex_exists(edges[i][1]);
      vertex* dest = vertex_exists(edges[i][2]);
      edge* e = new edge(edges[i][0], false, src, dest);
      this->e.push_back(e);
    }
  }
  // This method finds the MST of a graph using
  // Prim's Algorithm
  // returns the weight of the MST
  int find_min_spanning_tree(){
    int vertex_count = 0;
    int weight = 0;
    // Add first vertex to the MST
    vertex* current = g[0];
    current->setVisited(true);
    vertex_count++;
    // Construct the remaining MST using the
    // smallest weight edge
    while(vertex_count < g.size()){
      edge* smallest = NULL;
      for(int i=0; i<e.size(); i++){
        if(e[i]->isVisited() == false){
          if (e[i]->getSrc()->isVisited() == true
              && e[i]->getDest()->isVisited() == false) {
                if (smallest == NULL) {
                  smallest = e[i];
                }
                else if (e[i]->getWeight() < smallest->getWeight()) {
                  smallest = e[i];
                }
          }
        }
      }
      smallest->setVisited(true);
      smallest->getDest()->setVisited(true);
      weight += smallest->getWeight();
      vertex_count++;
    }
    return weight;
  }
  void print_graph() {
    for (int i = 0; i < g.size(); i++) {
      cout << g[i]->getId() << ' ' << g[i]->isVisited()
        << endl;
    }
    cout << endl;
    for (int i = 0; i < e.size(); i++) {
      cout << e[i]->getSrc()->getId() << "->"
        << e[i]->getDest()->getId() << "["
        << e[i]->getWeight() << ", "
        << e[i]->isVisited() << "]  ";
    }
    cout << endl << endl;
  }
  void print_mst(int w){
    cout << "MST\n";
    for(int i=0; i<e.size(); i++){
      if(e[i]->isVisited() == true){
        cout << e[i]->getSrc()->getId() << "->"
          << e[i]->getDest()->getId() << endl;
      }
    }
    cout << "weight: " << w << endl;
    cout << endl;
  }
};
void test_graph1() {
  graph g;
  int v = 5;
  // each edge contains the following: weight, src, dest
  vector<vector<int> > e = { { 1, 1, 2 }, { 1, 1, 3 }, { 2, 2,
                                                        3 }, { 3, 2, 4 }, { 3, 3, 5 }, { 2, 4, 5 } };
  g.generate_graph(v, e);
  g.print_graph();
  cout << "Testing graph 1...\n";
  //g.print_graph();
  int w = g.find_min_spanning_tree();
  g.print_mst(w);
}
void test_graph2() {
  graph g;
  int v = 7;
  // each edge contains the following: weight, src, dest
  vector<vector<int> > e = { { 2, 1, 4 }, { 1, 1, 3 }, { 2, 1,
                                                        2 }, { 1, 3, 4 }, { 3, 2, 4 }, { 2, 3, 5 }, { 2, 4, 7 },
                            { 1, 5, 6 }, { 2, 5, 7 } };
  g.generate_graph(v, e);
  cout << "Testing graph 2...\n";
  //g.print_graph();
  int w = g.find_min_spanning_tree();
  g.print_mst(w);
}
int main() {
  test_graph1();
  test_graph2();
  cout << "Completed!" << endl;
  return 0;
}

Solution Explanation#

Runtime Complexity#

Quadratic, O(n2)O(n2)

Here, ‘n’ is the number of vertices.

Memory Complexity#

Linear, O(n + e)

Here, ‘n’ is the number of vertices and ‘e’ is the number of edges.

Solution Breakdown#

A spanning tree of a connected, undirected graph is a subgraph that is a tree and connects all the vertices together. One graph can have many different spanning trees. A graph with n vertices has a spanning tree with n-1 edges.

A weight can be assigned to each edge of the graph. The weight of a spanning tree is the sum of weights of all the edges of the spanning tree. A minimum spanning tree (MST) for a weighted, connected and undirected graph is a spanning tree with a weight less than or equal to the weight of every other spanning tree.

We’ll find the minimum spanning tree of a graph using Prim’s algorithm. This algorithm builds the tree one vertex at a time, starting from any arbitrary vertex. It adds the minimum weight edge from the tree being constructed to a vertex from the remaining vertices at each step.

The algorithm is as follows:
